Pro/ENGINEER Tutorial Wildfire 4. 0 and MultiMedia CD

The eleven lessons in this tutorial introduce students to Pro/ENGINEER's Wildfire 4.0 design capabilities. The tutorial covers the major concepts and frequently used commands required to advance from a novice to an intermediate user level. Major topics include part and assembly creation, and creation of engineering drawings. Also illustrated are the major functions that make Pro/ENGINEER a parametric solid modeler.

Although the commands are presented in a click-by-click manner, an effort has been made, in addition to showing/illustrating the command usage, to explain why certain commands are being used and the relation of feature selection and construction to the overall part design philosophy. Moreover, since error recovery is an important skill, considerable time is spent exploring the created models (in fact, intentionally inducing some errors), so that users will become comfortable with the "debugging" phase of model creation.

At the end of each lesson is a short quiz reviewing the new topics covered in that chapter. Each lesson concludes with a number of simple "exercise" parts that can be created using new commands taught in that lesson. In addition to these a project is also included that consists of a number of parts that are introduced with the early lessons and finally assembled at the end.
