Creo Parametric 3.0: Cable and Harness Design

As an experienced user in the basics of Creo Parametric 3.0, this student guide enables you to create electromechanical cabling systems designed in Creo Parametric using the Piping and Cabling Extension. Utilizing the parametric and associative nature of Creo Parametric, an electromechanical designer can easily create realistic 3D cabling assemblies, wire lists, bill of material tables, and nail-board drawings. The Creo Parametric 3.0: Cable and Harness Design student guide contains numerous labs to give you practical experience that will improve your job performance.

The content in this student guide was developed using Build M110 of Creo Parametric 3.0.

Topics Covered

• Cabling Process Overview
• Cabling Terminology
• Environment and Configuration Setup
• Electromechanical Model Setup
• Manual Designation and Parameters
• Manual Spools
• Manual Cabling Features
• Logical Reference Technique
• Routing Methods
• Modifying Cabling Assemblies
• Additional Routing Features
• Networking
• Cabling Assembly Deliverables
• HARNESS-MFG

Prerequisites

We recommend that students have completed the Creo Parametric 3.0: Introduction to Solid Modeling student guide, or have equivalent experience.
