Creo Parametric 4.0: Sheet Metal Design

The Creo Parametric 4.0: Sheet Metal learning guide enables you to use your introductory modeling skills to create sheet metal models, including wall, bends, notches, and form features. On completion of this course, you will have acquired the skills to confidently manipulate sheet metal geometry, adjust bend developed lengths, and convert solid parts.

This guide was developed against Creo Parametric 4.0 Build M020.

Topics Covered

• The sheet metal environment
• Primary and secondary walls
• Bend relief
• Corner relief
• Regular unbends, back bends, and cuts
• Notches and punches
• Bend features
• Unbending complex geometry
• Sheet metal forms
• Documenting a sheet metal part
• Converting solid parts
• Sheet metal setup
• Investigating a sheet metal part

Prerequisites

Creo Parametric: Introduction to Solid Modeling or equivalent Creo Parametric 4.0 experience.
